5000W Sonicator Powerful Ultrasonic Homogenzier

Ultrasonic technique as a physical means and tools, can produce various extreme conditions in the liquid, a phenomenon known as sonochemistry, ultrasonic equipment related is called ultrasonic chemical equipment (referred to as "the sound of chemical equipment"). Ultrasonic dispersing device is an application of acoustic chemical equipment, can be used for water treatment, solid dispersion of particles in a liquid system, disaggregation, promoting effect of solid-liquid reaction etc.

Ultrasonics for nanodispersion of new materials, chemical extraction, biodiesel production, organic synthesis, treatment of microorganisms, degradation of pollutants, chemical reaction rate and yield, catalyst effects, biodegradation treatment, etc., promotes intense interaction between particles Increase chemical reaction rate, shorten reaction time, and reduce reaction conditions
Due to the cavitation in the liquid, the micro-jet, vibration and other phenomena are formed. On the microscopic level, the suspended particles in the liquid act as a high-speed stirring, dispersing, breaking and separating.

 Advantage

l  No need to change customer's existing production equipment and technological process.

l  It can be upgraded to a general equipment by using a simple installation.

l  It have less investment on a new technology, production and efficiency are improved obviously.

l  It has no moving parts, no electromagnetic radiation, fixed installation is very simple.

l  Suitable for the high pressure high temperature, toxic, explosive dangerous environment application.

l  Low power consumption, adaptation of wide, equipment almost don't have to do any modification.

5000W Sonicator Powerful Ultrasonic Homogenzier

Special Features

• Pre-selection of the required Amplitude (20 to 100%).

• Fully Automatic Frequency Servo-Control.

• Microprocessor Controlled Timer 0 to 24 Hours.

• Continuous Display of Time, Temperature & Ultrasonic Power.

• Pre-selection of different Time, Temperature & Ultrasonic Power required is possible.

• Stabilization of Amplitude within +/- 1%.

• High specific Ultrasonic Power, direct interaction between processing medium & Ultrasonic Probe.

• Individual & Application specific versions can be made.

• Can be installed for Online Continuous & Batch Processes.

• As per requirement additional SONO PROCESSORS can be added in series.

• Degassing of processing medium is possible.













  Description




  Type	YPS55B-HB	YPS57B-HB	YPS59B-MB	YPS61B-MB	YPS63B-MB
  Power	1000W	1500W	2000W	3000W	5000W
  Frequency	20Khz				20Khz
  Amplitude/power adjustment range	50-100%		20-100%		20-100%
  Temperature	＜100℃				＜100℃
  Volume of reactor	5-10L				30L-50L
  Standard Spec	Ultrasonic device + Digital Generator
  Optional configuration	Stainless steel reactor, Remote communication interface, flow meter, soundproof box

Application Fields

• Particle size reduction

• Homogenization

• Dispersion /Suspension

• Crystallization

• Emulsification /Mixing

• Degassing

• Disruption of Cells

• Agglomeration /De-agglomeration

• Acceleration of various chemical reactions, etc

• Viscosity Reduction

• Improves the Extract Yield and Extraction Efficiency.

• Accelerated processes and therefore increase in production      capacity.

• Cost savings due to faster process runs reduced work steps.

• Improved yield and increase in efficiency.

• Reduces quantity of solvent required.

• Suitable for almost all types of Solvents.
